Raise RT4
Raise RT4 Shimano Nexus 7-speed coaster brake / V-Brake
  • Wave 28" 45 cm / 50 cm / 55 cm
  • Trapez 28" 45 cm / 50 cm / 55 cm
  • Diamant 28" 50 cm / 55 cm / 60 cm
Colour:
rubinrot matt (only Wave, Trapez), green blue matt (only Wave, Trapez), dark blue matt (only Diamant)
Price (incl. Vat.) 615.41 €
Händler finden » Compare »

Raise RT4

Shimano Nexus 7-speed coaster brake / V-Brake

Category: Bicycle / City bike

Agile and dynamic – the everyday allrounder

Specs

Framesize
Diamant 28": 50, 55, 60 cm
Trapez 28": 45, 50, 55 cm
Wave 28": 45, 50, 55 cm
Frame
Aluminium 6061, 28" City
max load
120 kg
Color
dark blue matt, rubinrot, rubinrot matt, green blue matt
Fork
Suntour CR7V,
Head set
Chin Haur, 1 1/8” semi integrated
Shifting System
Shimano Nexus 7-speed coaster brake
Damper
N/V
Derailleur
N/V
Brakes
Alhonga V-Brake rim brake
Headlights
AXA Echo LED, 15 LUX including standinglight
Rear light
Trelock LS 655, including standinglight
Carriers
strutless, with spring flap
Saddle
Selle Royal Rio
Seat post
Promax aluminum, suspension, 27.2 mm, 300 mm
Pedals
Marwi SP-823, black
Kickstand
Ursus side kickstand
Chainguard
chain case, plastic
Mudguard
SKS, plastic
Weight
18.2 kg
Stem
Promax MQ-565, Aluminium, angle adjustable, 4-speed clamp
Handlebars
Trekking, steel, 600 mm
Grips
Herrmans DD37, with clamp
Shift lever
Shimano Nexus, twist grip
Brake lever
Promax, Aluminium, 3-finger brake lever
Tires
Schwalbe Citizen, 42-622, reflex
Rims
Schürmann YAK19 Aluminium hollow section, 36 holes
Spokes
Niro 2.0 mm
Front Hub
Shimano DH-C3000, hub dynamo, 36 holes
Rear Hub
Shimano Nexus 7-speed SG-C3001-7C, 36 holes, coaster brake
Sprocket
Shimano, 19 teeth
Chain
KMC S1
Inner bearing
Thun Twist 2.0
Bottom bracket
steel, plasticized, 170 mm, 38 teeth
Gear ratio (front:rear)
38 teeth : 19 teeth
Show all specs + Show less specs Product data sheet
